2.5GBase-T Discrete Lan Magnetics

You are welcomed to come to JASN factory to buy the latest selling, low price, and high-quality 2.5GBase-T Discrete Lan Magnetics. We look forward to cooperating with you.This V96T06D is 2.5G Base-T Quad Port Magnetics Module.

Model:V96T06D

Model:V96T06D

Send Inquiry

PDF DownLoad

You can rest assured to buy customized 2.5GBase-T Discrete Lan Magnetics from JASN. We look forward to cooperating with you, if you want to know more, you can consult us now, we will reply to you in time!


Feature


Comply with ROHS requirements.
Comply with IEEE802.3bz
Operating temperature range: 0℃to+70℃.
Storage temperature range: -25℃ to +125℃.

Electrical Specifications @ 25℃



OCL:

150uH Min. @100KHz/0.1V

Hi-Pot:

1500Vrms

Turn Ratio:

1:1±2%

LK:

0.5uH    Max @100KHz/0.2V

Cw/w

35pF Max @100KHz/0.2V

D.C.R:

1.0 ohm Max



Insertion Loss:

1-100MHz

100-200MHz

-1.0dB Max

-2dB Max



Return Loss:

1-40MHz

40-250MHz

-16dB Min

-16+10log（f/40）Min



Cross Talk :

1-200MHZ：:-25dB Min

CMRR:

1-200MHZ：-20dB Min
